goodtoothdoc
New Member
I am looking to buy a set (new or used) fo Magnum 500 wheels. What to I need to know? The front has DISC BRAKES and the rear has fender skirts. Is the following correct: 15 x 7, 4 on 5 1/2 with 4.25 back spacing?
1968 Chrysler New Yorker with Disc Brakes
- Thread starter goodtoothdoc
- Start date
carguy300
Senior Member
That is what was on my 68 300. The 300 I have now has 14" magnum 500's, this one has drum brakes.
carguy300
Senior Member
I ran 235/70-15's all the way around on my first one.
volksworld
Well-Known Member
the original magnum 500's were 14 inch and won't work with discs...newer reproduction ones come in 15's so this might limit the ability to find used ones....5 on 4 1/2, which i'm sure is what you meant to type
bigmoparjeff
Senior Member
Looks like Magnum 500's are a no-go with Budds:
Magnum 500 wheel issues
Hi, I am wanting to put a set of Magnum 500 wheels on my 68 New Yorker, i am looking at the Vintique ones, i can buy them locally here, I tried a 15 x 7 but it fouls on the factory Budd calipers. Is there a Magnum wheel that will clear the caliper in 15 x7 or 15 x 6, Also the Ford rims are...
www.forcbodiesonly.com
68-NewYorker
Member
If you have a 440, you got 15" wheels standard I believe. Mine had 15s and I found a 15" Vintique (Magnum 500 knock off) wheel that works. Required spacers to move them out from the disc calipers on the front.
carguy300
Senior Member
My 68 300 has 440, came with 14" magnums. It has 4 wheel drum.
cbarge
World Famous Barge in a Budget
Following this thread.
I have the 15 inch Wheel Vintiques on the drum brake Newport.
Was thinking swapping them onto my Budd disc brake 67 Monaco.
I have the 15 inch Wheel Vintiques on the drum brake Newport.
Was thinking swapping them onto my Budd disc brake 67 Monaco.
carguy300
Senior Member
That might be a tough decision! I like the hub caps on the dodge!, some hubcaps just belong! Both awsome cars!!
68-NewYorker
Member
68-NewYorker
Member
Must have been the disc brakes that gave the car 15" wheels and not the 440. Thanks.
58Special
New Member
All 67 and 68 300's only came with 440
Drum brakes had 14" wheels. If you ordered disc brakes they came with 15" wheels and hubcaps that stated disc brakes. There were no 15" magnum wheels available for chrysler 67-68.
Drum brakes had 14" wheels. If you ordered disc brakes they came with 15" wheels and hubcaps that stated disc brakes. There were no 15" magnum wheels available for chrysler 67-68.
carguy300
Senior Member
I think according to the sales broshure, 68 was the first year they were offered on the 300. 14" for drum and 15" on disc brake.
58Special
New Member
My 67 300 drum brake 14" magnum 500 wheels
carguy300
Senior Member
Are they factory?
carguy300
Senior Member
Heres 67 with magnums.
commando1
Old Man with a Hat
"Goodtoothdoc"
Did anyone else catch that?
Did anyone else catch that?
58Special
New Member
Yes
RemCharger
Active Member
First year what was offered?? 15" magnums??
cbarge
World Famous Barge in a Budget
67 first year Chrysler offered Magnum 500 full chrome but only in 14 inch.
Optional on all models including 300.
Yes I had seen a few 68 300 born with the 14 inch Magnums.
Either the dealer or owner checked the right box.
Later on Ma had a road wheel similar to a Magnum but chrome only on spokes and has a trim ring.
Again only in 14 inch.
Ford did offer a 15 inch Magnum 500 as an option on 1969 Boss Mustangs.
Although " not correct" yet look " factory stock" I went with 15 inch Magnums on my drum brake Newport.
